LCD 3D Printing

LCD 3D Printing

A resin-based 3D printing technology. Providing high-quality parts with quick printing timeframes.

Cost-effective | Quick turnarounds | Highly detailed

Get A Quote

What is Liquid Crystal Display (LCD) 3D Printing?

LCD 3D Printing uses a CAD file to build a part layer by layer from UV-sensitive resin being cured by a light source. This is similar to DLP & SLA.

Benefits

  • High detail.
  • Quick print times.
  • Smooth surfaces.
  • Can print transparent parts.
  • Can print rubber-like parts.

Applications

  • Dental purposes
  • Props/Models
  • Flexible parts.
  • Transparent parts.
LCD 3D Printing

Specifications

Machine Martrix 520
Layer Thickness 0.05-0.15mm
XYZ 298 x 165 x 320mm
Pixel Size 65 Microns
Materials

AME 520 Flexi

AME 520 White

AME 520 Cast

AME 520 Solvent-free

AME 520 Tough

AME 520 Clear



LCD Printing

Get LCD 3D Printed Parts

Get an instant quote.

Submit CAD

Materials

If the material you require isn't listed, please contact our sales team.

AME 520 White

IMG_3940

Prints smooth, high-detailed surfaces.

Has a high heat-deflection temperature, is strong & efficient.

Download
Datasheet

AME 520 Clear

AME 520 Clear Website-1

Produces transparent 3D parts.

Highly permeable resin.

Download
Datasheet

AME 520 Flexi

AME 520 Flexi Website-1

A Colorless transparent resin, with a shore hardness of 75A.

Has excellent tear resistance & resilience.

Download
Datasheet

AME 520 Cast

AME 520 Cast Website-1

High-speed builds suitable for dental purposes.

No post-curing needed.

Download
Datasheet

AME 520 Tough

IMG_2368

An opaque grey resin.

Ideal for creating strong parts.

Download
Datasheet

AME 520 Solvent-Free

AME 520 Solvent-Free Website-1

Prints smooth surfaces.

Ideal for parts required to be strong, with a good heat deflection temperature.

Download
Datasheet

Finishes

  • Post-curing.
  • Supports removed.

Optional: Bead blast.

Note: Scarring from build layers is still visible.

Everything included in standard finishing plus the additional features below.
  • Dry and wet sanding to remove build lines.
Everything included in the standard & advanced finishes, plus the additional extras below.
  • Primer.
  • Specific finish.
  • Gloss, Matte, Satin, Spark finish.
LCD 3D Printing

Need some more 3D printing help?

Download our guide to getting cost-effective manufacturing & understanding
which process suits your application.

Download Guide

LCD 3D Printing FAQs

LCD printing uses photosensitive resins, available in different types, including:

  • Standard resin (for general-purpose prints)
  • Tough resin (for impact-resistant parts)
  • Flexible resin (for rubber-like parts)
  • Dental and medical resins (for biocompatible applications)
  • Castable resin (for jewelry and casting applications)
  • Jewelry (casting and fine-detail designs)
  • Dental and medical (custom prosthetics, dental models)
  • Miniatures and figurines (high-detail prints)
  • Engineering prototypes (concept models and functional parts)
LCD 3D printing is relatively fast, with most prints taking 24 hours, depending on factors like layer height, part size, and complexity.

We have created a design guide with specifications for our 3D printing, vacuum casting and reaction injection moulding technologies.

You can download this here.



Alternatively, if you require assistance with CAD design, we have our own design department. Send an email to design@ame-3d.co.uk.

LCD 3D Printing Quote

Supporting businesses with our LCD 3D printing services for over 20 years.



High quality LCD parts guaranteed
1-6 Day lead times
6 Materials Available
Excellent Customer Service & CAD Advice Provided
ISO 9001:2015 certified

Submit the form > Receive a quote within 24-48 hours > Order & get your parts

Need an NDA? Download it here & send it to info@ame-3d.co.uk.
