Selective laser sintering 3D printing

SLS 3D Printing

A highly precise 3D printing process that cost-effectively produces industrial-strength parts.

Cost-effective | Lead times from 1 day | High-quality

What is Selective Laser Sintering (SLS)?

Selective Laser Sintering 3D printing uses a CAD file to build a part layer by layer from nylon-based powder which is fused together with a laser.

SLS 3D printing is among the most versatile additive manufacturing technique that enables both low volume production and precision part manufacturing.

Benefits

  • No Support Structures.
  • Repeatability.
  • Suitable for mechanical testing.
  • Can print complex geometries.
  • Can print high-strength parts.

Applications

  • Consumer products.
  • Functional prototypes.
  • Jigs & Fixtures.
  • Automotive & Aerospace parts.
  • Mechanical components.
SLS 3D Printing

Specifications

Dimensions 330 x  280 x  400mm
Resolution Layer Thickness 0.1mm
 Clearances Min 0.8mm
Wall Thickness 0.8mm - 2.0mm  (varies with material choices)
Tolerances

± 0.3mm  or  ±0.05 mm / mm

Engraving

Minimum depth of 1mm
-- Text must have a min. font size of 2mm

Embossed Details

Minimum height of 1mm

Holes

Greater than 1.5mm diameter

Escape Holes

Minimum 3.5mm diameter



SLS 3D Printing Service

Get SLS 3D Printed Parts

Submit Your CAD files for a quote.

Materials

If the material you require isn't listed, please contact our sales team.
AME Nylon PA 650 Material
  • A versatile, highly-robust chemical resistant SLS material.
  • Ideal for prototypes and end-use products. Can be sprayed painted any colour.
AME Nylon GF 615 Material
  • 50% Glass filled nylon.
  • Well suited for automotive engine components or parts that
    require complex
    geometries.
AME PA 2210 FR Material
  • Blue Card Certified. FAR 25.853 compliant.
  • Ideal for manufacturing flame-resistant parts that have high-mechanical properties.

Finishes

  • Loose powder removed.
  • Bead blast.
  • Colour spray painting / colour dye.
  • Vapour smoothing.
  • Shot peening.
  • Dying black.
  • Water resistant sealing.
  • Fully bespoke custom finish.
Selective laser sintering 3D Printing

SLS 3D Printing Quote

Supporting businesses with our SLS 3D printing services for over 20 years.



High quality SLS parts guaranteed
1-6 Day lead times
3+ Materials Available
Excellent Customer Service & CAD Advice Provided
ISO 9001:2015 certified

Submit the form > Receive a quote within 24-48 hours > Order & get your parts

Need an NDA? Download it here & send it to info@ame-3d.co.uk.
